Submersible Sewage Pump

Submersible Sewage Sludge Pumps Jubl Series

In past few decades industrial manufacturing sector has grown with a rapid pace leading to higher living standards. This has also led to major problem by form industrial effluent and household sewage. Vast quantities of waste water have damaged the eco system and polluted our water source to a great extent. Toshio Technology has been making every endeavor in developing the waste water treatment equipment. In addition to waste water pumps and sewage pumps, the company has developed submersible aerator for efficient treatment rate of waste water. These aerators have been widely used in domestic and overseas waste water treatment plants.

Toshio offers multiple product option for sewage transfer application. Depending upon size and type of sewage treatment plant customer can select sewage pump from 0.5hp to 100 hp. Solid size can be upto 100mm depending on capacity of the motor.

A submersible pump (or sub pump, electric submersible pump (ESP)) is a gadget which has a hermetically fixed engine close-coupled to the pump body. The entire get together is submerged in the liquid to be pumped. The principle favorable position of this sort of pump is that it counteracts pump capitation, an issue related with a high height contrast amongst pump and the liquid surface. Submersible pumps push liquid to the surface instead of fly pumps pulling liquids. Submersibles are more proficient than fly pumps.

Electric submersible pumps are multistage centrifugal pumps operating in a vertical position. Liquids, accelerated by the impeller, lose their kinetic energy in the diffuser where a conversion of kinetic to pressure energy takes place. This is the main operational mechanism of radial and mixed flow pumps.

Application :-

JUBL is a reliable pump for a wide range of applications.

Ideal for civil works, tunneling and industrial sites.

Technical Data :-
Flow Range 300 lpm
Max. Head -
Liquid Temp. 5`~40` C
Frequency -
Spherical Clearance Upto 38 mm
MOC Pump casing is steel coated & impller is thermo plastic SS304 motor housing
Performance Curve :-

JDS Series - Submersible Sewage Pump


Range: 1/2HP - 15HP
Features :-

Light weight Submersible Sludge Pump for Solids Handling

Both impeller and pump casing made of wear-resistant material by DUPONT

Circumferential cooling allows the pump to operate in continuous snoring mode.

Robust SUS304 outer casing.

With air vent- allows the pump to work above water surface and motors still gets cooled by water.

Large free passage up to 38mm.
